Isenberg 196.4301MB 3/4x22 Thermostatic Valve with 3-Way Diverter and Trim Matte Black

Description

In case, the tile is thicker or valve installed in the wall is too deep, extension kits are available and can be used for elongating both handles of the valve. This will ensure that the trim plate will cover the cut out hole in the wall. ANTI-SCALD RING – Over the temperature control knob, is an anti-scald temperature stop ring which is a safety feature in this thermostatic value. CUT OUT DIMENSIONS – The cut out in wall should be 6.49” x 4.44” Inches which is properly covered by the trim plate. The trim plate is used to cover the wall. With the help of this ring, the temperature of the water is regulated. The bottom handle sets the temperature. SUPPLY STOPS – There are two safety stops at each water inlet to prevent water flow in case of installation and repairs. The top handle is capable of controlling the volume of water from full flow to a trickle. In order to adjust the water temperature, one needs to press this button and move the handle to a hot or cold direction. Also, the value must be installed straight and not at an angle or upside down. Product Documents SPECIFICATION SHEET PARTS DIAGRAM Installation Installation Documents. This product meets CAL-Green compliance criteria. Covering this ring is the handle knob which has a push-button on the side. The diverter handle on the top diverts the flow from each of the three outputs of the valve. TRIMS – The trims comprise of a well-finished cover plate and handle knobs. Each port has full volume control capability.

Key Features

• The anti-scald temperature stop ring should be fitted tightly over the valve (tapping using a rubber mallet might be required) for it to function properly.
• The top handle controls water diversion between the 3 water output ports.
• TRIMS – The trims comprise of a well-finished cover plate and handle knobs.
• ANTI-SCALD RING – Over the temperature control knob, is an anti-scald temperature stop ring which is a safety feature in this thermostatic value.
• Isenberg 3/4′′ Thermostatic Valve with 3-Way Diverter and Trim 196.4301 Product Description SPECIFICATIONS: Solid Brass Valve & Trim Includes Thermostatic Valve Diverts water between 3 outlets.
• VALVE INSTALLATION – As the valve is installed, care should be taken to maintain a proper distance from the back of the valve to the finished tile which should be between 2.77” and 3.44” inches [Rough In Spec].
